Architects · Specifiers · Designers
Welcome to UGS for industry professionals
A patented, New Zealand-made structural glazing system with the engineering documentation, span data and CAD detail you need to specify it with confidence.
Specify with confidence
ClearSpan is a patented universal mounting and sealing system that accommodates glass, polycarbonate and acrylic from 4mm to 16mm in the same framework. That means one detail can carry a change of glazing material late in a project without redrawing the structure.
Everything is manufactured at our Kumeu factory in West Auckland from New Zealand-made aluminium, so lead times, finishes and section sizes are all confirmed locally. Powder coating is available across the full Dulux Duralloy range.
For consented work, PS1 producer statements cover both polycarbonate and glass, and span charts state maximum spans by glazing type, thickness and load. Polycarbonate options are NZBC Group 1-S rated where flame retardancy is required.
What you can specify
-
System
ClearSpan Box
Integrated aluminium rafter for greater structural support and a clean, modern soffit line. Full range of posts, beams and brackets.
-
System
ClearSpan Plus
Reinforced sections and brackets for extended spans where post positions are constrained by the architecture.
-
System
ClearSpan Bar
Bar system that fixes to existing rafters or purlins — suited to retrofit and re-roofing over existing structures.
-
Glazing
Glass, Polycarbonate, Acrylic
One universal mounting and sealing method takes 4mm to 16mm glazing, so material can change without redrawing the frame.
-
Finish
Powder coat & anodised
Full Dulux Duralloy range with a 10 year durability warranty, plus anodised components.
-
Add-on
Ziptrak outdoor blinds
Clear PVC, sunscreen mesh or acrylic canvas screens, manual or motorised, integrated into the same opening.
Documentation for your project file
- ClearSpan Span Chart (PDF, opens in a new tab) Maximum spans by glazing type, thickness and load.
- UGS PS1 — Polycarbonate and Glass (PDF, opens in a new tab) Producer statement covering polycarbonate and glass systems.
-
UGS Installation and Flashing Details Standard junction, flashing and fixing details.
- Masterspec & EBOSS Specification clauses and our full EBOSS library.
Working on a project now?
Send us the drawings and we will confirm spans, sections and glazing options before you document it. Everything else — Masterspec clauses, EBOSS listings, install details — sits in Technical Resources.
